HYTORC

EDGE

HYDRAULIC TORQUE WRENCH

HYTORC EDGE is the low-priced, compact and universally deployable square-drive torque wrench that still offers you the speed and easy-to-use features normally found only in the top of the line wrenches. Its universal push-through square drive enables quick switch between the loosening and tightening operation. This tool is a perfect and most cost-effective option for the basic maintenance jobs in any industry.

  • 360° turning reaction fixture is attached to the rear of the wrench
  • 360° x 180° uni-swivel for easy setup of tool and hoses
  • Manufactured especially for maintenance industries
  • Wide range of reaction fixtures
  • Supplied with a calibration certificate
  • Supplied with a carry handle (on EDGE-2 and larger models)
  • Supplied with a robust heavy-duty case
Category:

Description



EDGE
ITEM Drive Torque Range (Nm) R (mm) L (mm) H (mm) W (mm) Weight (kg)
EDGE-.5S 3/4″ 144 – 962 21 102 75 42 1,5
EDGE-2S 3/4″ 241 – 1703 25 125 90 50 1,8
EDGE-4S 1″ 600 – 4172 33 163 120 67 3,9
EDGE-6S 1 1/2″ 1 210 – 8457 40 193 153 81 8,7
EDGE-8S 1 1/2″ 1 667 – 11 592 47 221 167 91 9,1
EDGE-12S 1 1/2” 2 188 – 15 299 50 244 180 100 11
EDGE-30S 2 1/2″ 6 027 – 40 176 71 348 257 143 29



Brand

HYTORC

HYTORC

HYTORC is the world’s leader in hydraulic and pneumatic torque wrench manufacturing. With over 50 years of experience focused entirely on developing the highest quality industrial bolting systems, HYTORC is the most trusted name in the industry. The latest product line features patented industry-firsts like hands-free operation, onboard documentation systems and industry-leading bolt load accuracy to reduce nut loosening and joint failure. Haitor has been cooperating with HYTORC throughout its whole lifetime. Visit manufacturer's website >>
HYTORC

Torque Charts

EDGE-.5 [PDF] EDGE-2 [PDF] EDGE-4 [PDF] EDGE-6 [PDF] EDGE-8 [PDF] EDGE-12 [PDF] EDGE-30 [PDF]

Product Sheet

Product Sheet (in Finnish) [PDF]
