HYTORC

jGun Single Speed

PNEUMATIC TORQUE WRENCH

HYTORC jGun Single Speed guarantees a safe, fast and easy bolt tightening operation that gets bolts tightened with ±5% accuracy. The precision gearing produces constant, calibrated power with reduced recoiling. The no impacting making operation is not just very user friendly and quiet, also very safe.

  • Model cover a wide 70 – 10700 Nm torque range
  • No impacts and therefore vibration-free and low noise
  • Ergonomic grip
  • Improved work safety – safety paddle needs to be pressed down to operate tool
  • Durable lightweight high-strength aluminium alloy body
  • Unprecedented performance for its weight and size
  • Compatible with HYTORC Washers, J-Washers and NUT fastening elements for maximum bolt load accuracy

Description



jGun Single Speed
ITEM Torque Range (Nm) Drive Bolt Size (M) D (mm) L (mm) H (mm) Weight (kg) Free Speed (rpm)
JGUN-A.25 81 – 373 3/4″ M12 – M16 64 179 186 3,3 65
JGUN-A.5 237 – 678 3/4″ M14 – M22 66 205 186 3,3 24
JGUN-A1 271 – 1 695 3/4” M20 – M30 66 226 186 4,5 6,5
JGUN-A2 735 – 2 630  1″ M20 – M36 83 266 202 6,6 5,5
JGUN-A3 881 – 4 203  1″ M27 – M42 83 282 202 7,2 5
JGUN-A5 1 627 – 7 050  1 1/2″ M36 – M48 105 322 210 9,1 2,5
JGUN-A8 2 407 – 10 894 1 1/2” M42 – M56 116 353 215 12 1,5



Brand

HYTORC

HYTORC

HYTORC is the world’s leader in hydraulic and pneumatic torque wrench manufacturing. With over 50 years of experience focused entirely on developing the highest quality industrial bolting systems, HYTORC is the most trusted name in the industry. The latest product line features patented industry-firsts like hands-free operation, onboard documentation systems and industry-leading bolt load accuracy to reduce nut loosening and joint failure. Haitor has been cooperating with HYTORC throughout its whole lifetime. Visit manufacturer's website >>
HYTORC

Product Sheet

Product Sheet (in Finnish) [PDF]
